Antec Sonata Proto - Case Specifications

P 6
1.2 C ASE S PECIFICATIONS
Case Type
Mid Tower
Color
Piano Black
Dimensions
19.5 " (H) x 10.5" (W) x 21.5" (D)
495mm (H) x 266.7mm (W) x 495mm (D)
Weight
9.1kg / 20.2 lbs
Cooling
1 x Rear 120mm TriCool™ LED fan
1 x Front 120mm fan mount (optional)
Drive Bays
10 Drive Bays:
- 3 x External 5.25” drive bays
- 2 x Internal 3.5” drive bays
- 4 x Internal 3.5” drive bays
Expansion Slots 7
Motherboard Size
Mini-ITX, microATX, Standard ATX
Front I/O Panel
2 x USB 2.0
External eSATA
AC’97 / HD Audio In and Out
1.3 P ARTS I NCLUDED
In addition to the accessories stored inside your computer, your box should also contain the following:
Illustration No. Part Qty
1 Front panel keys 1
2 5.25” drive bay thumb screw 16
3 HDD mounting screws 15
4 Fan screw 4
5 Motherboard standoffs 9
6 Drive tray screw 15
7 Motherboard screws 13
8 Optical drive screws 18
9 Case decal 1
1
2
3
4
5
6
7
8
9
