7. ADVANCED SET-UP continued …
TRIGGERS / IR / RS232 Example: Activate Trigger1 and 2 when MAIN is turned ON with TV as the Source.
• Enter the Setup Menu (section 7.1). Go to ‘8. TRIGGERS/IR/RS-232’ and press SELECT (‘Select’).
• Upon entering this menu item, “8a. ALL TRIGGERS: Disabled” will be highlighted in red.
• Use the 34 keys (MASTER CONTROL KNOB) to change to ‘Enabled’.
• Press the 6 (‘Down’) key to go to “b. SET TRIGGER 1”.
• Press SELECT (‘Select’).
• Use the 65 (‘Down’ / ‘Up’) keys to go to ‘TV’.
• Press SELECT (‘Select’).
• Use the 65 keys (MASTER CONTROL KNOB) to change the ‘-’ to ‘*’.
• Press the EXIT (‘ B a c k ’) key twice to leave this submenu.
• Press the 6 (‘Down’) key to go to “c. SET TRIGGER 2”.
• Press SELECT (‘Select’).
• Use the 65 (‘Down’ / ‘Up’) keys to go to ‘TV’.
• Press SELECT (‘Select’).
• Use the 65 (‘Down’ / ‘Up’) keys to change the ‘-’ to ‘*’.
• Press the EXIT (‘ B a c k ’ ) key to leave the submenu and return to the Setup Menu.
7.4.9 DISPLAYS / SELECTION TIME
This Setup Menu allows you to configure both the On-Screen display, Front Panel display and Selection Time.
(menu 9.a) On-Screen:
‘Bypassed’ turns the On-Screen display OFF; ‘Enabled’ turns it ON. If you choose ‘Bypassed’, you will have
to rely solely on the Front Panel display.
(menu 9.b) On-Screen Out:
With the On-Screen ‘Enabled’ you will then have to choose which output the On-Screen display will be
directed to, either ‘Composite’ or ‘S-Video’. If you have the Video Output of the AVM 2 connected to the
Composite Video Input of your TV Monitor, choose ‘Composite’. If you have the Video Output of the AVM 2
connected to the S-Video Input of your TV Monitor, choose ‘S-Video’.
9. DISPLAYS/SELECTION TIME
a. ON-SCREEN : Enabled
b. ON-SCREEN OUT : Composite
c. SELECTION TIME : 5 s
d. ON-SCREEN POS’N : Bottom
e. Z2 INFO ON MAIN OS : Yes
f. FRT PANEL-HI : 15
g. FRT PANEL-MED : 12
h. FRT PANEL-LOW : 8
i. FP WAKE-UP : Up 1
