Anthem MCA 525 User Manual

IMPORTANT INFORMATION FOR UK CUSTOMERS: DO NOT cut off the mains
plug from this equipment. If the plug fitted is not suitable for the power points
in your home or the cable is too short to reach a power point, then obtain an
appropriate safety approved extension lead or consult your dealer. If, nonetheless,
the mains plug is cut off, REMOVE THE FUSE and dispose of the PLUG
immediately, to avoid possible shock hazard by inadvertent connection to the
mains supply. If this product is not provided with a mains plug, or one has to be
fitted, then follow the instructions given below:
IMPORTANT: DO NOT make any connection to the larger terminal which is
marked with the letter “E” or by the safety earth symbol or colored GREEN
or GREEN AND YELLOW.
The wires in the mains lead on this product are colored in accordance with the
following code:
BLUE – NEUTRAL
BROWN – LIVE
As these colors may not correspond with the colored markings identifying the
terminals in your plug, proceed as follows:
The BLUE wire must be connected to the terminal marked with the letter
“N” or colored BLACK.
The BROWN wire must be connected to the terminal marked with the letter
“L” or colored RED.
When replacing the fuse, only a correctly rated and approved type should
be used, and be sure to re-fit the fuse cover. If in doubt consult a competent
electrician.
iii

Anthem MCA 525 Specifications

General

Damping factor	300
Amplifier class	-
Input sensitivity	150 mV
Audio output channels	5.0 channels
Peak power per channel	225 W
Signal-to-Noise Ratio (SNR)	120 dB
Total Harmonic Distortion (THD)	0.001 %
On/off switch	Yes
Product color	Black
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	2 W
Power consumption (typical)	550 W
XLR out	5
Speakers connectivity type	XLR / RCA

Weight and Dimensions

Depth	460 mm
Width	439 mm
Height	169 mm
Weight	27500 g
