6 PVA AMPLIFIERS
TECHNICAL SPECIFICATIONS
INPUTS PVA 2 2 Single-ended, 1 Relay Trigger (3.5 mm Mono Jack)
PVA 5 5 Single-ended, 1 Relay Trigger (3.5 mm Mono Jack)
PVA 7 7 Single-ended, 1 Relay Trigger (3.5 mm Mono Jack)
OUTPUTS PVA 2 2 Pairs Speaker Binding Posts, 1 Relay Trigger (3.5 mm Mono Jack)
PVA 5 5 Pairs Speaker Binding Posts, 1 Relay Trigger (3.5 mm Mono Jack)
PVA 7 7 Pairs Speaker Binding Posts, 1 Relay Trigger (3.5 mm Mono Jack)
SWITCHES Front Panel: Power On/Off
Rear Panel: 3 On/Off Modes: Trigger, Manual, Auto
POWER OUTPUT (Continuous, RMS, 20 Hz - 20 kHz, <1.0% THD, AC line voltage held constant at full load).
)
Impedance: 8 Ω 4 Ω 2 Ω
# of Channels Driven: 1 All 1 All 1 All
PVA 2, PVA 5, PVA 7 125 W 105 W 200 W 140 W 300 W -
HEADROOM 1.25 dB (8 Ω); 2.13 dB (4 Ω)
POWER BANDWIDTH 10 Hz - 80 kHz (125 W @ 8 Ω)
FREQUENCY RESPONSE 20 Hz - 20 kHz, (-0.20 dB); 5 Hz - 100 kHz, (-2.5 dB)
THD&N <0.002%, @ 1 kHz; <0.03% @ 20 kHz (125 W into 8 Ω)
INPUT SENSITIVITY 1.12 VRMS for 125 W into 8 Ω
INPUT IMPEDANCE 10k Ω
DAMPING FACTOR 200 @ 1 kHz (ref. 8 Ω)
S/N RATIO 122 dB, A-weighted (ref. 125 W)
CHANNEL SEPARATION >65 dB (100 Hz - 10 kHz)
VOLTAGE GAIN 29 dB
SLEW RATE 28 V/µs
POWER REQUIREMENTS PVA 2 500 VA @ maximum power output (8 Ω load)
PVA 5 1125 VA @ maximum power output (8 Ω load)
PVA 7 1500 VA @ maximum power output (8 Ω load)
DIMENSIONS PVA 2 17
1
/
4
” (44 cm) Wide x 5
1
/
4
” (13.5 cm) High x 11” (28 cm) Deep
PVA 5 17
1
/
4
” (44 cm) Wide x 5
1
/
4
” (13.5 cm) High x 13
1
/
4
” (33.5 cm) Deep
PVA 7 17
1
/
4
” (44 cm) Wide x 5
1
/
4
” (13.5 cm) High x 16
3
/
8
” (42 cm) Deep
NET WEIGHT PVA 2 26 lbs (12 kg)
PVA 5 36 lbs (16.5 kg)
PVA 7 47.5 lbs (21.5 kg)
NOTE: Measurements were performed with an Audio Precision System Two @ 120 VAC
