1.2 Wall Mounting
Measure the distance between two hanging holes and draw position symbols on the wall. Attach
two screws (not provided) into the wall according to the symbols. Match screws to hanging
holes and place screws into hanging holes to hang the antenna. Antenna can be positioned
horizontally or vertically (horizontal mounting illustrated below).
Fig. 1.2
Top View of Stand
Slot for horizontal sliding in
Tab for vertical mounting support
Cable Wiring
