Antop AT-215BB - Attic Placement; Connecting the Antenna

2 / Connecting
Connect the coaxial cable to the ANTENNA/CABLE IN connector on the back of the TV or
converter box. Connect the power adapter to the DC socket in Smartpass Amplifier.
3
Back of TV
CABLE IN
ON/OFF LED
ANT/IN
2
1.2.1
1.3 Attic Placement
Antenna can be placed in an attic, either in horizontal or vertical position. Local a suitable area
in your attic and follow the table top mounting with stand installation instructions from above.
Horizontal Mounting
Hanging hole Hanging hole
