DiaLog Elite PLC Interface Manual
0
– Low Limit (disabled)
1 – High Limit (disabled)
2 – Positive Rate of Change (disabled)
3 – Negative Rate of Change (disabled)
4 – Rate of Change Period (disabled)
3
Alarm Delay [0-65535 seconds] (3)
4
Continue alarm notification if return to normal
0
– Disabled 1 – Enabled
5
Telephone list [1-16] (1)
6
Relay channel to activate [0 – disabled, 11-98]
Relay state on Normal to High Alarm is
0 – De-energized 1 – Energized 2 – Disabled
Relay state on High Alarm to Normal is
0 – De-energized 1 – Energized 2 – Disabled
Relay state on Normal to Low Alarm is
0 – De-energized 1 – Energized 2 – Disabled
Relay state on Low Alarm to Normal is
0 – De-energized 1 – Energized 2 – Disabled
De-energize on alarm acknowledge
0 – Disabled 1 – Enabled
7
Channel Alphanumeric ID (CHAN nn)
.
12 Version 1.2 © Antx, inc. 2001
