DiaLog Elite PLC Interface Manual
Relay Outputs
After entering the Register Type (Write Coil) and Register Number the Elite drops
down into the section that allows entering alarm and channel processing information.
n n.
Channel Number [11-98]
0
Pulse Duration [0-86400 seconds] (0)
2
Channel Mode
0
– Disabled
1 – Status Only
3
Channel Alphanumeric ID (CHAN nn)
4
Relay ID message
©
Antx, inc. 2001 Version 1.2 13
