AOC 22B1H

Specification
General Specification
Panel
Model name
22B1H
Driving system
TFT Color LCD
Viewable Image Size
21.5inch, 54.7cm diagonal
Pixel pitch 0.24825(H)mm x 0.24825(V)mm
Video R, G, B Analog Interface & HDMI Interface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Others
Horizontal scan range
30~83KHz
Horizontal scan
Size(Maximum)
476.64mm
Vertical scan range
50Hz ~ 76Hz
Vertical scan Size(Maximum)
268.11mm
Optimal preset resolution 1920x1080@60Hz
Plug & Play VESA DDC2B/CI
Input Connector
D-Sub 15 pin/HDMI
Power Source
19Vdc, 1.31A
Power Consumption
Typical (Brightness = 90,Contrast = 50)
17W
(Brightness = 100,Contrast = 100) ≤19W
Power saving ≤0.5W
Physical
Characteristics
Connector Type
D-Sub/ HDMI/ Earphone out
Signal Cable Type
Detachable
Environmental
Temperature:
Operating
0° to 40°C
Non-Operating -25° to 55°C
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating
5% to 93% (non-condensing)
Altitude:
Operating
0~ 5000m(0~ 16404 ft)
Non-Operating
0~ 12192m (0~ 40000 ft )
46
