AOC 24B2XD User Manual

26
Panel
Model name 24B2XDA
Driving system TFT Color LCD
Viewable Image Size 60.47cm diagonal
Pixel pitch 0.2745(H)mm x 0.2745(V) mm
Video R, G, B Analog Interface & HDMI Interface & DVI Interface
Separate Sync H/V TTL
Display Color 16.7M Colors
Others
Horizontal scan range
30-85kHz
Horizontal scan Size(Maximum) 527.04mm
Vertical scan range 48-75Hz
Vertical Scan Size(Maximum) 296.46mm
Optimal preset resolution 1920x1080@60Hz
Max resolution
1920x1080@60Hz(VGA/DVI)
1920x1080@75Hz(HDMI)
Plug & Play VESA DDC2B/CI
Power Source 19Vdc,1.31A
Power Consumption
Typical(default brightness and contrast) 19W
Max. (brightness = 100, contrast =100) ≤ 23W
Standby mode ≤0.3W
Physical
Characteristics
Connector Type HDMI/DVI/D-Sub/Audio in/Earphone out
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )

AOC 24B2XD Specifications

General

Certification	True
Product color	Black
Detachable stand	Yes
Heavy metals free	Hg (mercury)
Market positioning	Home
Color depth	8 bit
Aspect ratio	4:3, 16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	Matt
Display diagonal	23.8 \
Surface hardness	3H
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
Supported video modes	720p, 768p, 1080p
NTSC coverage (typical)	72 %
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	60.452 cm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (typical)	13.5 W
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
Sustainability certificates	WEEE
HDMI	-
DisplayPorts quantity	0
HDMI cable length	1.8 m
Power cable length	1.5 m
Package type	Box
Package depth	131 mm
Package width	614 mm
Package height	492 mm
Package weight	4500 g
Exterior finish type	Textured
Recyclable packaging material	100 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	170.94 mm
Height (with stand)	418.35 mm
Weight (with stand)	2700 g
Depth (without stand)	37.6 mm
Width (without stand)	539.47 mm
Height (without stand)	320.94 mm
