AOC 712SI User Manual

17” LCD Color Monitor AOC 712Si
44
J906 95G 90 23 TINCOATEDCOPPER
J907 95G 90 23 TINCOATEDCOPPER
J908 95G 90 23 TINCOATEDCOPPER
R833 95G 90 23 TINCOATEDCOPPER
R834 95G 90 23 TINCOATEDCOPPER
R908 61G 17218252T 1.8KOHM 5% 1/4W
R806 61G 17247152T 470OHM 1/4W
R905 61G 20747052T 47 OHM 1/2W
R913 61G 20747052T 47 OHM 1/2W
R836 61G 60251152T CFR 1/6W 510OHM +-5%
R903 61G212Y15352T RST MGFR 15 KOHM +-5% 1
R809 61G212Y625 KT MGFR 6.2MOHM +-5% 1/2W
R814 61G212Y625 KT MGFR 6.2MOHM +-5% 1/2W
D902 93G 6026T52T FR107-DO-41 1000V/1A
D903 93G 6038P52T PS102R DO-41 200V/1A
IC903 56G 158 4 T H431BA
C923 64G700J1040AT 0.1UF 50V PEN
C918 65G 2K152 1T6052 1.5NF/2KV Y5P +-10%
C914 65G517K102 5T 1000PF 10% Y5P 500V
C915 65G517K102 5T 1000PF 10% Y5P 500V
C920 67G 2151097NT 1UF/50V
C909 67G 305100 7T
105℃ 10UF+-20% 50
F901 84G 55 7W 250V/3.15A FUSE
Q901 57G 667 21 Transistor STP10NK70ZFP
90G6263 1 HEAT SINK
M1G1730 8128 CR3 SCREW
90G6263 1 HEAT SINK
D901 93G 60245 DIODE SP10150 ITO-220
M1G1730 8128 CR3 SCREW
BOM for PWB
SMTC5CNNA1QP
Location Part No. Description
CN3 33G802315A H WAFER
CN4 33G802315A H WAFER
IC3 56G 379 64 CT1102
U2 56G 562122CA4 NT68621MEFG-64
U3 56G 563 75 G1084-33T43UF TO-252
IC2 56G 563 76 G960T63UF SOT-223
U4 56G 563 77 G952T43UF TO-252
IC1 56G 643 19 G675L240T1U
