17” LCD Color Monitor AOC 712Si
7
3.3 Adjusting the Picture
1. Press the MENU-button to activate the OSD window.
2. Press < or > to select the desired function.
Once the desired function is highlighted, press the MENU-button to
activate it. If the function selected has a sub-menu, press
< or > again to navigate through the sub-menu functions. Once
the desired function is highlighted, press MENU-button to activate it.
3. Press < or > to change the settings of the selected function.
4. To exit and save, select the exit function. If you want to adjust any other function, repeat steps 2-3.
Main Menu Item
Main Menu
Icon
Sub Menu
Item
Sub Menu
Icon
Description
Contrast
Contrast from Digital-register.
Luminance
Brightness
Backlight Adjustment
Focus
Adjust Picture Phase to reduce Horizontal-Line noise
Image Setup
Clock
Adjust picture Clock to reduce Vertical-Line noise.
H. Position
Adjust the horizontal position of the picture.
Image Position
V. Position
Adjust the vertical position of the picture.
Warm N/A
Recall warm Color Temperature from EEPROM.
Cool N/A
Recall cool Color Temperature from EEPROM.
User / Red
Red Gain from Digital-register.
User / Green
Green Gain Digital-register.
Color Temp.
User / Blue
Blue Gain from Digital-register.
