49
SPECIFICATIONS
A2072PWH
LCD Panel
Driving system 19.5” WLED
Size 49.5cm diagonal
Pixel Pitch 0.27mm(H) × 0.27mm(V)
Input
Video
R, G, B Analog Interface
Digital
Separate Sync. H/V TTL
H-Frequency 30kHz ~ 83kHz
V-Frequency 50 ~ 76Hz
Display Colors 16.7M Colors
Dot Clock 170MHz
Max. Resolution 1600×900@60Hz
Plug & Play VESA DDC2B™
LAN Speed 10/100Mbps
RF Module M/N WSDB-673GN
Power Consumption
ON Mode 30W (Typ.)
Standby Mode
≤
1W (VGA/HDMI),
≤
10W (Android)
OFF Mode
≤
0.5W
Input Connector
D-Sub 15pin
HDMI 19pin
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM, positive or negative
HDMI: Differential Input Voltage 150~1200mV
Power Source
Input: 100~240VAC, 50/60Hz
Output: DC 19V
Environmental Considerations
Operating Temp.: 0° to 40°C
Storage Temp.: -20° to 60°C
Operating Humidity: 15% to 90%
Dimensions 489.1(W) x 297.8(H) x 43.8(D) mm
Weight (N. W.): 2.9 kg
