AOC e1649Fwu Service Manual

17
5.2 USB Board
715G5071T01000004S
GND
Route diff pairs to 90ohms differential impedance
Type A => mini Type
VBUS0
GND
GND
FB002
120 OHM
1 2
12345
CN002
MINI USB CONN
1
2
3
4
5
67 89
DMU
DPU
GND
R002 NC
VBUS0
L001
90OHM
1
4
2
3
C001
100N 16V
ZD002
NC
1 2
R001 NC
ZD001
NC
1 2
CN001
CONN
1
2
3
4
5
67
USB_DP
USB_DN
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹 C
AOC e1649Fwu
A
2 2Thursday, April 28, 2011
715G
< 称爹 >
2. USB board
USB_DN
USB_DP
FB001
120 OHM
1 2

AOC e1649Fwu Specifications

General

3D	No
Pixel pitch	0.252 x 0.252 mm
Aspect ratio	16:9
Display surface	-
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Vertical scan range	30 - 50 Hz
Horizontal scan range	30 - 60 kHz
Viewable size, vertical	193.5 mm
Viewing angle, vertical	50 °
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	500:1
Display number of colors	16.78 million colors
Viewable size, horizontal	344.2 mm
Viewing angle, horizontal	90 °
Display brightness (typical)	200 cd/m²
Supported graphics resolutions	1366 x 768, 640 x 480 (VGA)
USB hub version	2.0
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	1
Certification	EPEAT, cULus, FCC, RoHS, EPA 5.0
Product color	Black
Plug and Play	Yes
Panel mounting interface	- mm
Power consumption (standby)	- W
Power consumption (typical)	8 W
Package depth	101 mm
Package width	444 mm
Package height	301 mm
Package weight	1700 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	35.5 mm
Width (without stand)	376 mm
Height (without stand)	236 mm
Weight (without stand)	1060 g
