AOC e1649Fwu Service Manual

23
2. No Video (Power LED Blue)
No Video (Power LED Blue)
Press the power
button is OK?
Check the LVDS/FFC
cable or panel
The end
NG
OK
OK
NG
Replace the main board
Replace the converter
board
Replace the LVDS/FFC
cable or panel
NG
The end
Replace the key board
NG
OK
Replace the main
board and connection
OK

AOC e1649Fwu Specifications

General

3D	No
Pixel pitch	0.252 x 0.252 mm
Aspect ratio	16:9
Display surface	-
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Vertical scan range	30 - 50 Hz
Horizontal scan range	30 - 60 kHz
Viewable size, vertical	193.5 mm
Viewing angle, vertical	50 °
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	500:1
Display number of colors	16.78 million colors
Viewable size, horizontal	344.2 mm
Viewing angle, horizontal	90 °
Display brightness (typical)	200 cd/m²
Supported graphics resolutions	1366 x 768, 640 x 480 (VGA)
USB hub version	2.0
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	1
Certification	EPEAT, cULus, FCC, RoHS, EPA 5.0
Product color	Black
Plug and Play	Yes
Panel mounting interface	- mm
Power consumption (standby)	- W
Power consumption (typical)	8 W
Package depth	101 mm
Package width	444 mm
Package height	301 mm
Package weight	1700 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	35.5 mm
Width (without stand)	376 mm
Height (without stand)	236 mm
Weight (without stand)	1060 g
