AOC e2060Sn User Manual

Input Select
Auto /Analog Select Input Signal Source
Auto Config yes or no Auto adjust the picture to default
Off timer 0-24hrs Select DC off time
Image Ratio wide or 4:3 Select wide or 4:3 format for display
DDC-CI yes or no Turn ON/OFF DDC-CI Support
Reset
Yes or no Reset the menu to default
Information
Show t he infor mation of the main image and
sub-image source
32

AOC e2060Sn Specifications

General

3D	No
HD type	-
Pixel pitch	0.276 x 0.276 mm
Aspect ratio	16:9
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Vertical scan range	50 - 75 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	249.1 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	442.8 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	200 cd/m²
Supported graphics resolutions	1600 x 900
On/off switch	Yes
Ethernet LAN (RJ-45) ports	0
Number of products included	1 pc(s)
LED indicators	Power
Cable lock slot type	Kensington
Number of OSD languages	15
Panel mounting interface	100 x 100 mm
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	25 W
Power consumption (standby)	0.5 W
Safety	RoHS
Certification	cTUVus, FCC, CE, TUV/S, Windows 7
Product color	Black
Cables included	AC
Bundled software	Screen+
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package depth	115 mm
Package width	534 mm
Package height	420 mm
Package weight	3930 g
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (without stand)	185 mm
Width (without stand)	511 mm
Height (without stand)	373 mm
Weight (without stand)	2680 g
