AOC E2243Fw User Manual

43
C79,C911 0CH2473H562 47NF, K, 25V, X7R, 0.9MM, 1608, R/TP
C56,C57,C58,C59,C74 0CH2473K562 47NF 50V K X7R 1608 R/TP
C36,C908 0CH2A-0007A
1U F, 10 VOLT, K PER, X5R(JB), 1608 R/TP,
T=0.9(MAX)
C50,C55 0CH2A-0010A 33NF, M, 25V, X7R, 0.9MM, 1608,R/TP
C22,C23,C32,C33,C34 0CH2A-0011A
10U F, 16 VOLT, K PER, X5R(JB), 3216 R/TP,
T=0.95(MAX)
C101,C102,C103,C104,
C105,C106,C107,C108,
C109,C110,C111,C112,
C113,C114,C301,C303,
C305,C307,C309,C311,
C77,C907
0CH2A-0015A 1UF, K, 25V, X5R, 0.9MM, 1608, R/TP
C73 0CH2A-0017A
2.2U F, 10 VOLT, K PER, X5R(JB),
1608 R/TP, T=0.9(MAX)
C313,C314,C315,C318,
C52,C61,C62,C63,C64,
C71,C72,C913,C914,
C920,C921
0CH2A-0026A
10U F, 25 VOLT, K PER, X5R(JB),
3225 R/TP, T=1.0(MAX)
C1,C2,
,C312,C5,C6,C7,C8
0CH2A-0038A
0.1U F, 25 VOLT, Z PER, Y5V(JF),
1005 R/TP, T0.55(MAX)
C701 0CH2A-0049A 1.5NF, 50, -10~+10(K), 1608, X7R(JB)
C75 0CH2A-0088A 3.3NF, K, 50V, X7R, 0.9MM, 1608, R/TP
C3,C4,C912 0CH2A-0091A 1UF, K, 25V, X5R, 0.6MM, 1005, R/TP
D3,D4,D5 0DHZL-0008B BAV99-7-05-F, DIODES, SOT-23, R/TP
ZD1 0DHZL-0061A SDZ6V2D, AUK, SOD-323, R/TP
D6 0DHZL-0095A RB050M-30, ROHM, PMDU, R/TP
F1 0FFST-0002A
F0603FA2500V032T, AEM, 2.5, 32 VOLT,
1.6X0.8X0.8, SMT, CERAMIC, UL/CSA
U3 0IDIL-0002A
AP7167-FNG-7,DIODES,
A
DJUST_3.3V, 1.2A,
DFN3030-10, R/TP, 10
UC2 0IIML-0004A
IML7821BE, IML, 5V~20V, 320MA, 20V/US,
40MHZ, 1CH, TSOT, R/TP, 5PIN
U4 0ISGL-0008C
M24C04-RDW, STMICROELETRONICS,
4K, 5MS, TSSOP, R/TP, 8
US2 0ISML-0007A
SM4025, SILICON MITUS, MONITOR,
BOOST+L/S(GPM)+OP-AMP+PVCOM+DISC
HARGING,
UC1 0ISWL-0078A
SW0640, SIW, LVDS, 6/8, 2, MINI-LVDS,
6, 1, DRD, GIP, AFRC, DGA, MUTE, MLF,
TR, 68
