43
NO. DESCRIPTION NO. PART NO. DESCRIPTION
1 BEZEL L215W-TB1-TBP1 4 0M1G-140--6125 SCREW(TILT SUPPORT BRACKET/ REAR COVER)
2 PANEL LM215WF4-TRA2 FQ LTD 6 0M1G-940--5125 SCREW(HINGE /TILT SUPPORT BRACKET)
3 REAR COVER L215W-TB1-TBP1 16 0M1G1730--6120 SCREW(MAIN BOARD/ SHIELD_MAIN_BASE)
5 TILT SUPPORT BRACKET 17 MAIN BOARD
7 BASE COVER TOP 18 SHIELD
8 HINGE FRONT COVER 19 0Q1G-140-10120 SCREW(BASE/ SHIELD_MAIN_BASE)
9 HINGE BACK COVER 20 FOOT PAD
10 SHEET 21 0M1G-140--8125 SCREW(SHIELD_MAIN_BASE / HINGE)
11 KEY BOARD
12 LENS
13 HINGE 21.5
14 BASE TRIM
15 SHIELD COVER
To Next Page
