AOC e2243Fw2 User Manual

46
U4 0ISGL-0008C
M24C04-RDW, STMICROELETRONICS, 4K,
5MS, TSSOP, R/TP, 8
US2 0ISML-0007A
SM4025, SILICON MITUS, MONITOR,
BOOST+L/S(GPM)+OP-AMP+PVCOM+DIS
CHARGING,
UC1 0ISWL-0078A
SW0640, SIW, LVDS, 6/8, 2, MINI-LVDS, 6,
1, DRD, GIP, AFRC, DGA, MUTE, MLF, TR,
68
L1 0LCAA-0069A
TNI8016-100M, DACOWELL, 10UH, M20,
2.1A, 0.093, 8.0X11.0X1.8
(1.2MM,IN-BOARD), R/TP
FL4,FL5,R103,R109,
R118,R119,R121,R125,
R126,R127,R129,R138,
R139,R140,R142,R179,
R180,R20,R302,R4,R54,
R601,R602,R801,R802,
R906,R908
0RH0000C622 0 OHM 1/16W 1608 5% D R/TP
R131 0RH0102C422 10 OHM 1/16W 1608 1% D R/TP
R701,R901,R902,R903 0RH0221C622 2.2 OHM 1/16W 1608 5% D R/TP
R10,R11,R12,R13,R14,
R15,R16,R17,R18,R19,
R22,R23,R25,R26
0RH0302C422 30 OHM 1/16W 1608 1% D R/TP
R322 0RH0472C422 47 OHM 1/16W 1608 1% D R/TP
R150,R2,R3 0RH1000C422 100 OHM 1/16W 1608 1% D R/TP
R1 0RH1001C422 1K OHM 1/16W 1608 1% D R/TP
R24,R27,R55 0RH1002C422 10K OHM 1/16W 1608 1% D R/TP
R123 0RH1102C422 11K OHM 1/16W 1608 1% D R/TP
R244 0RH1202C422 12K OHM 1/16W 1608 1% D R/TP
R151,R242,R254 0RH1502C422 15K OHM 1/16W 1608 1% D R/TP
R114,R136,R211,R214 0RH1601C422 1.6K OHM 1/16W 1608 1% D R/TP
R130,R234,R777 0RH1602C422 16K OHM 1/16W 1608 1% D R/TP
R224 0RH1802C422 18K OHM 1/16W 1608 1% D R/TP
R225,R232,R235 0RH2002C422 20K OHM 1/16W 1608 1% D R/TP
R141 0RH2200C422 220 OHM 1/16W 1608 1% D R/TP
R115 0RH2201C422 2.2K OHM 1/16W 1608 1% D R/TP
R50,R51 0RH2401C422 2.4K OHM 1/16W 1608 1% D R/TP
R222,R255,R904 0RH2402C422 24K OHM 1/16W 1608 1% D R/TP
R261 0RH2700C422 270 OHM 1/16W 1608 1% D R/TP
R148,R212,R213,R245 0RH3302C422 33K OHM 1/16W 1608 1% D R/TP
R223 0RH3303C422 330K OHM 1/16W 1608 1% D R/TP
