AOC e2243Fw2 User Manual

55
033G801910Y--H FPC CONN. 0.5MM SMT 10P 2
nd
source
715G4604M0C000004I MAIN PCB FR4 DS 146X115*1.6 6
F40G0003615-1A E43FW2-E943F2 POP LABEL
KEPCAQQR KEY BOARD
CN001 033G8032-7F--S--HR CONNECTOR 7P 1.25
U001 056G-669-15 TEST ONLY IT7230BFN
R005,R006 061G0402000-JT RST CHIPR MAX0R05 1/16W TZAI YUAN
061G0402000-JY RST CHIPR 0 OHM -5% 1/16W YAGEO
R004 061G0402101-JT RST CHIP 100R 1/16W 5% TZAI YUAN
061G0402101-JY RST CHIPR 100 OHM -5% 1/16W YAGEO
R001,R002,R003 061G0402103-JT RST CHIP 10K 1/16W 5% TZAI YUAN
061G0402103-JY RST CHIPR 10KOHM -5% 1/16W YAGEO
R007,R008,R009,R010,
R011,R012
061G0402472-JT RST CHIP 4K7 1/16W 5% TZAI YUAN
061G0402472-JY RST CHIPR 4.7KOHM -5% 1/16W YAGEO
C008 065G040210131J---Y CAP CHIP 0402 100P 50V NPO +/-5%
065G040210131J---T CAP CHIP 0402 100PF 50V NPO
C005,C006,C007 065G040210427Z---T CAP CHIP 0402 0.1UF 25V Y5V
C011,C013 065G0402105A7Z---A CAP CHIP 0402 1UF 10V Y5V
065G0402105A7Z---Y CAP CHIP 0402 1UF Z 10V Y5V
065G0402105A7Z---3 CAP CHIP 0402 1UF Z 10V Y5V
C003,C004 065G040212031J---Y CAP CHIP 0402 12P 50V NPO +/-5%
065G040212031J---T CAP CHIP 0402 12PF 50V J NPO
LED001 081G--15--2-EL
LED WHITE/RED 12-22/T7R8D-D30/2C
SMD
LED002,LED003,
LED004,LED005
081G-15W--1-EL CHIP LED WHITE
709G4164-QS001 COMSUPTIVE ASS'Y
E715 715G4164K01000004F KEY PCB FR4 DS97X23X1.0MM
715G4164K01000004M KEY PCB FR4 DS97X23X1.0MM 2
nd
source
Q36G-600517 DUSTER CLOTH
Q40G-22E61539A
LABEL RATING FOR E2243FW2_E2343F2
KOREA
Q40G000161521A CARTON LABEL FOR KOREA
Q40G000361596A POP LABEL(WIN 7+EPEAT+EPA)
Q40G0003615A85 KOREA STICKER LABEL
Q40G0003615A97 LABEL WARNING FOR KR WHITE
Q41G78D1615-4A CARD
Q41G78S161557A E2243FW2/E2343F2 QSG
Q44GB059615-8B AOC E2243FW2 SERIES CARTON
