AOC E2260PWHU - Page 58

58
C701 0CH2A-0049A 1.5nF,50,-10~+10(K),1608,X7R(JB)
C75 0CH2A-0088A 3.3nF,K,50V,X7R,0.9mm,1608,R/TP
C912 0CH2A-0091A 1uF,K,25V,X5R,0.6mm,1005,R/TP
D3,D4,D5 0DHZL-0008B BAV99-7-05-F,DIODES,SOT-23,R/TP
ZD1 0DHZL-0061A SDZ6V2D,AUK,SOD-323,R/TP
D6 0DHZL-0095A RB050M-30,ROHM,PMDU,R/TP
F1 0FFST-0002A
F0603FA2500V032T,AEM,2.5,32Volt,1.6X0.8
X0.8,SMT,Ceramic,UL/CSA
U3 0IDIL-0002A
AP7167-FNG-7,DIODES,ADJUST_3.3V,1.2A,
DFN3030-10,R/TP,10
UC2 0IIML-0004A
iML7821BE,IML,5V~20V,320mA,20V/us,40MH
z,1Ch,TSOT,R/TP,5Pin
U4 0ISGL-0008C
M24C04-RDW,STmicroeletronics,4K,5ms,TSS
OP,R/TP,8
US2 0ISML-0007A
SM4025,SILICONMITUS,MONITOR,BOOST+
L/S(GPM)+OP-AMP+PVCOM+DISCHARGIN
G,
UC1 0ISWL-0078A
SW0640,SIW,LVDS,6/8,2,MINI-LVDS,6,1,DR
D,GIP,AFRC,DGA,MUTE,MLF,TR,68
L1 0LCAA-0069B
TNI8016-100M,DACOWELL,10UH,M=20%,2.1
A,0.093,8.0X11.0X1.8(1.2MM,IN-BOARD),R/T
P
FL4,FL5,R103,R
109,R118,R119,
R121,R125,R12
6,R127,R129,R1
38,R139,R140,R
142,R179,R180,
R20,R302,R54,
R601,R602,R80
1,R802,R901,R9
02,R903,R906,R
908
0RH0000C622 0OHM1/16W16085%DR/TP
R131 0RH0102C422 10OHM1/16W16081%DR/TP
R701 0RH0221C622 2.2OHM1/16W16085%DR/TP
R10,R11,R12,R
13,R14,R15,R16
,R17,R18,R19,R
22,R23,R25,R26
0RH0302C422 30OHM1/16W16081%DR/TP
R322 0RH0472C422 47OHM1/16W16081%DR/TP
R2,R3 0RH1000C422 100OHM1/16W16081%DR/TP
