AOC e2260Sd Manual

51
Panel
Model name
E2060SWDA/ E2060PWDA
/E2060SW/E2060SWD
Driving system TFT Color LCD
Viewable Image Size 49.5cm diagonal
Pixel pitch 0.27mm(H)X0.27mm(V)
Video (E2060SWDA/
E2060PWDA/E2060SWD)
R, G, B Analog lnterface & Digital Interface
Video (E2060SW) R, G, B Analog lnterface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Dot Clock 108MHz
Resolution
Horizontal scan range 30 kHz - 83 kHz
Horizontal scan Size(Maximum) 432mm
Vertical scan range 50 Hz - 76 Hz
Vertical scan Size(Maximum) 239.76mm
Optimal preset resolution 1600×900@60Hz
Plug & Play VESA DDC2B/CI
Input Connector
(E2060SWDA/ E2060PWDA/E2060SWD)
D-Sub 15pin; DVI 24pin
Input Connector (E2060SW) D-Sub 15pin;
Input Video Signal Analog: 0.7Vp-p(standard), 75 OHM, TMDS
Power Source 100-240V~, 50/60Hz
Power Consumption
Active: 23 W (typical)
Standby < 0.5 W
Off timer 0-24 hrs
Speakers(E2060SWDA/ E2060PWDA) 2WX2
Physical Characteristics
Connector Type
(E2060SWDA/ E2060PWDA/E2060SWD)
15-pin Mini D-Sub DVI-D
Connector Type (E2060SW)
15-pin Mini D-Sub
Signal Cable Type Detachable
Environmental
Temperature:
Operating 0° to 40°
Non-Operating -25° to 55°
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 93% (non-condensing)
