AOC e2260Sd Manual

52
Panel
Model
name
E2260P
HU
/E2260
S
HU
/
E2260P
DA
/E2260S
DA
/E2260S
D
Driving system
TFT Color LCD
Viewable Image Size
5
5.86 cm
diago
nal
Pixel pitch
0.282mm(H) x 0.282mm(V)
Video
(
E2260P
HU
/E2260S
HU
)
R, G, B Analog lnterface & Digital Interface & HDMI lnterface
Video
(E2260PDA/E2260SDA/E2260SD)
R, G, B Analog lnterface & Digital Interface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Dot Clock
146
MHz
Resolution Horizontal scan range 30 kHz - 83 kHz
Horizontal scan Size(Maximum)
473.76mm
Vertical scan range 50Hz - 76 Hz
Vertical scan Size(Maximum) 296.1mm
Optimal preset resolution 1680 x 1050@60Hz
Plug & Play VESA DDC2B/CI
Input connector
(E2260PHU/E2260SHU)
D-Sub 15pin DVI 24pin，HDMI
Input connector
(E2260PDA/E2260SDA/E2260SD)
D-Sub 15pin DVI 24pin
Input Video Signal Analog: 0.7Vp-p(standard), 75 OHM, TMDS
Power Source 100-240V~, 50/60Hz
Power Consumption
Active
:
38
W
(
typical
)
Standby <
0.5
W
Off timer
0
-
24 hrs
Speakers(E2260PDA/E2260SDA
E2260PHU/E2260SHU)
2W x 2
Physical
Characteristics
Connector type
(E2260PHU/E2260SHU)
15-pin Mini D-Sub DVI-D,HDMI
Connector type
(E2260PDA/E2260SDA/E2260SD)
15-pin Mini D-Sub DVI-D
Signal Cable Type Detachable
Environmental
Temperature:
Operating 0° to 40°
Non-Operating -25°to 55°
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 93% (non-condensing)
