AOC E2270SWHN User Manual

40
Specification
General Specification
Panel
Product name
Driving system
TFT Color LCD
Viewable Image Size
diagonal
Pixel pitch
mm(H) x mm(V)
Video
R, G, B Analog lnterface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Dot Clock
Resolution
Horizontal scan range
Horizontal scan Size(Maximum)
Vertical scan range
50 Hz - 76 Hz
Vertical scan Size(Maximum)
Optimal preset resolution
Plug & Play
VESA DDC2B/CI
Input Connector
D-Sub 15pin
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM
Power Source
100-240V~, 50/60Hz
Power Consumption
Active：18 W(typical)
Standby < 0.5W
Physical
Characteristics
Connector Type
15-pin Mini D-Sub
Signal Cable Type
Detachable
Environmental
Temperature:
Operating
0° to 40°
Non-Operating
-25°to 55°
Humidity:
Operating
10% to 85% (non-condensing)
Non-Operating
5% to 93% (non-condensing)
Altitude:
Operating
0~ 3658m (0~ 12000 ft )
Non-Operating
0~ 12192m (0~ 40000 ft )
E2070SWN/E2070SWNL
49.41cm
0.2712*RGB
0.2626
170MHz
30 kHz - 83 kHz
433.92mm
236.34mm
1600 x 900@60Hz

AOC E2270SWHN Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	Matt
Pixel frequency	108 MHz
Display diagonal	21.5 \
Surface hardness	3H
Display technology	-
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	1080p
Viewable size, vertical	268.11 mm
Viewing angle, vertical	65 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	700:1
Display number of colors	16.7 million colors
Display brightness (peak)	- cd/m²
Display diagonal (metric)	54.61 cm
Viewable size, horizontal	476.64 mm
Viewing angle, horizontal	90 °
Display brightness (typical)	200 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Certification	True
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Home
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
Exterior finish type	Textured
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	19 W
HDMI version	1.4
DisplayPorts quantity	0
Headphone connectivity	3.5 mm
Package type	Box
Package depth	108 mm
Package width	558 mm
Package height	394 mm
Package weight	3450 g
VGA cable length	1.2 m
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR
Harmonized System (HS) code	85285210

Weight and Dimensions

Height (with stand)	375 mm
Weight (with stand)	2700 g
Depth (without stand)	48 mm
Width (without stand)	503.37 mm
Height (without stand)	311.1 mm
Weight (without stand)	- g
