9.White- Balance, Luminance Adjustment
Approximately 30 minutes should be allowed for warm up before proceeding white balance adjustment.
How to setting MEM channel you can reference to chroma 7120 user guide or simple use “SC” key and
“NEXT” Key to modify xyY value and use “ID” key to modify the TEXT description Following is the procedure to do
white-balance adjust .
1. Setting the color temp.
A. 6500K:
Warm color temp. parameter is x=313±20，y=329±20
B. 7300K
Normal color temp. parameter is x=301±20，y=317±20
C. 9300K
Cool color temp. parameter is x=283±20，y=297±20
D. sRGB
sRGB color temp. parameter is x=313±20，y=329±20
2. Enter into the factory mode:
2.1 Software:
DT_Toolbox
2.2 Install software:
2.2.1 Unzip to get .
2.2.2 Double-click to install the tool.
2.2.3 Click .
