4.3.3 Optical Characteristics
Electrical characteristics
Ta = 25°C
Parameter Symbol
Values
Unit
Min Typ Max
MODULE :
Power Supply Input Voltage V
LCD
4.5 5.0 5.5 Vdc
Permissive Power Input Ripple V
LCD
- - 0.3 V
Power Supply Input Current
I
LCD-MOSAIC
(60Hz)
- 1180 1540 mA
I
LCD-BLACK
(60Hz) - 1400 1820 mA
I
LCD-BLACK
(75Hz)
- 2260 mA
Power Consumption P
LCD
- 5.9 7.7 Watt
Inrush current I
RUSH
- - 3.0 A
LED bar Electrical characteristics
Ta = 25°C
Parameter Symbol Condition
Values
Unit
Min. Typ. Max.
LED :
LED String Current Is - 60 65 mA
LED String Voltage Vs - 57.6 59.9 V
Power Consumption PBar - 13.8 14.4 Watt
LED Life Time LED_LT 30,000 - - Hrs
