12
Connecting the Monitor
Cable Connections On Back of Monitor and Computer:
1.
Power
2. D-SUB
3.
DVI
To protect equipment, always turn off the PC and LCD monitor before connecting.
1 Connect the power cable to the AC port on the back of the monitor.
2 Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other end to the
computer's D-Sub port.
3
4 Turn on your monitor and computer.
If your monitor displays an image, installation is complete. If it does not display an image, please refer
Troubleshooting.
（Optional-Requires a video card with DVI port）-Connect one end of the DVI cable to the
back of the monitor and connect the other end to the computer’s DVI port.
