AOC e2351Fh Service Manual

45
6308L-3518A
LTBXNSSNEX5-02300T08, 521.60*297.60,
LGC, T, B, X, N, S, S, N, E, X, 5, 02300, Top,
08
6308L-3519A
LTXXNSSNEX5-02300B08, 524.60*297.60,
LGC, T, X, X, N, S, S, N, E, X, 5, 02300,
Bottom, 08
6871L-2543B
Source, Single, None-C/SKD,
LM230WF5-TJC1, Single Side
C1,C2,C5,C6,C7,C8 0CH2104H942 0.1uF, Z, 25V, Y5V, 0.9mm, 1608, R/TP
C70 0CH2153K562 15nF, K, 50V, X7R, 0.9mm, 1608, R/TP
C44,C51,C53,C71 0CH2473K562 47NF 50V K X7R 1608 R/TP
C12 0CH2474D572 0.47uF, K, 10V, X5R, 0.95mm, 1608, R/TP
C41 0CH2A-0006A
4.7U F, 16 Volt, K PER, X5R(JB), 3216 R/TP,
T=1.0(MAX)
C204,C3,C4,C77 0CH2A-0007A
1U F, 10 Volt, K PER, X5R(JB), 1608 R/TP,
T=0.9(MAX)
C32,C33,C73,C74 0CH2A-0011A
10U F, 16 Volt, K PER, X5R(JB), 3216 R/TP,
T=0.95(MAX)
C101,C102,C103,C1
04,C105,C106,C107,
C108,C109,C110,C1
11,C112,C113,C114,
C301,C303,C305,C3
07,C31,C42,C85,C90
4
0CH2A-0015A 1uF, K, 25V, X5R, 0.9mm, 1608, R/TP
C76 0CH2A-0017A
2.2U F, 10 Volt, K PER, X5R(JB), 1608 R/TP,
T=0.9(MAX)
C43,C50,C52 0CH2A-0019A
68N F, 50 Volt, K PER, X7R(JB), 1608 R/TP,
T=0.9(MAX)
C55,C56,C61,C62,C
64,C66
0CH2A-0026A
10U F, 25 Volt, K PER, X5R(JB), 3225 R/TP,
T=1.0(MAX)
C901,C903 0CH5680K412 68PF, J, 50V, 1608, R/TP, 0.9mm
C23 0CH5681K412 680PF 50V J NP0 1608 R/TP
C801 0CH5820K412 82PF 50V J NP0 1608 R/TP
D3,D4,D5 0DHZL-0008B BAV99-7-05-F, DIODES, SOT-23, R/TP
ZD1 0DHZL-0065A SDZ5V1D, AUK, SOD-323, R/TP
D6 0DHZL-0095A RB050M-30, ROHM, PMDU, R/TP
F1 0FFST-0009A
F0603FA3000V032TM, AEM, Ceramic, 32V,
3A, UL/CSA, 1.6X0.8X0.8mm, R/TP
U6 0IDIL-0002A
AP7167-FNG-7, DIODES, ADJUST_3.3V,
1.2A, DFN3030-10, R/TP, 10

AOC e2351Fh Specifications

General

Brand	AOC
Model	e2351Fh
Category	Monitor
Language	English
