AOC e2351Fh Service Manual

46
UC1 0ILDL-0001A
LDA5001A, LGD, LVDS, 6/8, 1/2,
MINI-LVDS, 6, 1, DRD, GIP, AFRC, DGA,
ODIN2, MLF, TR, 68
U4 0ISGL-0008C
M24C04-RDW, STmicroeletronics, 4K, 5ms,
TSSOP, R/TP, 8
US2 0ISML-0002A
SM4005, Silicon Mitus, TN MNT,
Boost+Op-Amp+L/S+D/C+PVcom, QFN
(7x7), R/TP, 48 pin
L1 0LCAA-0069B
TNI8016-100M, DACOWELL, 10UH, M=20%,
2.1A, 0.093, 8.0X11.0X1.8 (1.2MM,
IN-BOARD), R/TP
R203,R205,R215,R2
16,R225,R226,R300,
R303,R307,R308,R3
5,R362,R41,R42,R51
,R6,R7,R802,R803,R
806,R808,R83,R9
0RH0000C622 0 OHM 1/16W 1608 5% D R/TP
R28 0RH0102C422 10 OHM 1/16W 1608 1% D R/TP
R901,R903 0RH0221C622 2.2 OHM 1/16W 1608 5% D R/TP
R211,R212,R213,R2
14
0RH0302C422 30 OHM 1/16W 1608 1% D R/TP
R221,R222,R223,R2
24,R44,R45,R46,R47
0RH0562C422 56 OHM 1/16W 1608 1% D R/TP
R11,R12 0RH1000C422 100 OHM 1/16W 1608 1% D R/TP
R13,R140 0RH1001C422 1K OHM 1/16W 1608 1% D R/TP
R3,R5 0RH1002C422 10K OHM 1/16W 1608 1% D R/TP
R910 0RH1003C422 100K OHM 1/16W 1608 1% D R/TP
R118,R128 0RH1301C422 1.3K OHM 1/16W 1608 1% D R/TP
R807 0RH1500C422 150 OHM 1/16W 1608 1% D R/TP
R121,R131 0RH1501C422 1.5K OHM 1/16W 1608 1% D R/TP
R1,R906 0RH1502C422 15K OHM 1/16W 1608 1% D R/TP
R113,R63 0RH1601C422 1.6K OHM 1/16W 1608 1% D R/TP
R62,R909 0RH1602C422 16K OHM 1/16W 1608 1% D R/TP
R116,R119 0RH1801C422 1.8K OHM 1/16W 1608 1% D R/TP
R64 0RH2000C422 200 OHM 1/16W 1608 1% D R/TP
R125,R14,R81 0RH2001C422 2K OHM 1/16W 1608 1% D R/TP
R129 0RH2400C422 240 OHM 1/16W 1608 1% D R/TP
R10,R114,R123,R8,
R82
0RH2401C422 2.4K OHM 1/16W 1608 1% D R/TP
R104 0RH2402C422 24K OHM 1/16W 1608 1% D R/TP
R202 0RH2702C422 27K OHM 1/16W 1608 1% D R/TP
