10. Firmware and DDC Instruction
10.1 Firmware Instruction
Step 1: Operation Conditions:
1) An i486 (or above) personal computer or compatible.
2) Microsoft operation system Windows 95/98/2000/XP.
3) ISPTool programs
4) VGA cable & LPT cable
5) ISP board (PN: 715GT034-B，715GT048-1 or715GT035-A)
6) ISP Firmware/Software
7）For example：NOVATEK ICNT68668FGQFP-128
Step 2：Connection：
NO1. TPV Part No. : 715GT048-1 or 715GT035-A（715GT048-1 or 715GT035-A）
NO2. TPV Part No : 715GT034-B（NEW LCD EDID TOOL ：715GT034-B）
To PC LPT Port
Connect 12V power
To Monitor
To Next Page
