AOC E2461FWH Service Manual

56
C412
065G080510615K T
CHIP 10uF 16V X5R 0805
C451
065G080510615K T
CHIP 10uF 16V X5R 0805
C806
065G080522232K Y
CAP CHIP 0805 2N2 50V X7R +/-10%
C808
065G080522232K Y
CAP CHIP 0805 2N2 50V X7R +/-10%
C815
065G080547432K A
CAP CHIP 0805 0.47UF K 50V X7R
C803
065G080547432K A
CAP CHIP 0805 0.47UF K 50V X7R
C807
065G080547432K A
CAP CHIP 0805 0.47UF K 50V X7R
C720
065G120610625K A
CAP 1206 10UF 10% 25V X5R
C732
065G120610625K A
CAP 1206 10UF 10% 25V X5R
C723
065G120610625K A
CAP 1206 10UF 10% 25V X5R
FB403
071G 56K121 M
CHIP BEAD 120OHM 6A MGLB2012-120T-LF
FB406
071G 56K121 M
CHIP BEAD 120OHM 6A MGLB2012-120T-LF
FB404
071G 56K121 M
CHIP BEAD 120OHM 6A MGLB2012-120T-LF
FB402
071G 56K121 M
CHIP BEAD 120OHM 6A MGLB2012-120T-LF
FB401
071G 56K121 M
CHIP BEAD 120OHM 6A MGLB2012-120T-LF
FB108
071G 56K121 M
CHIP BEAD 120OHM 6A MGLB2012-120T-LF
FB702
071G 56K121 M
CHIP BEAD 120OHM 6A MGLB2012-120T-LF
FB501
071G 59G301 TA
CHIP BEAD 300OHM 200mA FCM1608KF-301T02
FB101
071G 59G301 TA
CHIP BEAD 300OHM 200mA FCM1608KF-301T02
FB104
071G 59K190 TA
CHIP BEAD 0603 19R 25% FCB1608KF-190T05
FB102
071G 59K190 TA
CHIP BEAD 0603 19R 25% FCB1608KF-190T05
FB103
071G 59K190 TA
CHIP BEAD 0603 19R 25% FCB1608KF-190T05
L801
073G253S 98 DN
SMD CHOKE 47UH 20% 0.064R LZ.29470.B2P
L701
073G253S521 H
SMD CHOKE 22UH 20% 3.3A HF
CN501
088G 34019H VD
HDMI HEADER 19P V/T H=10.5mm
D501
093G 60518SEM
SCHOTTKY BAT54C-HAF 0.2A 30V SOT-23
D101
093G 64 42 L
DIODE LBAV70LT1G SOT-23 LRC
ZD101
093G 39GA01 T
RLZ5.6B
ZD501
093G 39GA01 T
RLZ5.6B
D801
093G 60S907 T
SCHOTTKY B3100B 3A 100V SMB
D802
093G 64S511SEM
1N4148W
D701
093G3004 2
SR34 PAN JIT
CN405
311GF100C06ADH
FFC CONN 1.0mm 6P
CN802
311GW125D06AAX
CONN 1.25mm 6P S1315-06SVB-S03-R
U401
356G0562128B15
SCALER tsumo58bdc2-1 128-LQFP
U705
356G0563419
DC/DC APW7089KAI-TRG 4A 26V SOP-8P
U801
356G0700045
LED DRIVER PF7024 S SOP-16
R810
361G1206108AJF
RST 1206 0.1R 5% 1/4W RS-06MR10JT
R811
361G1206208AJF
RST 1206 0.2R 0.5% 1/4W RS-06MR20JT
709G57310HS001
COMSUMPTIVE ASSY
E715
715G5731M0E000004S
MAIN PCB FR4 DS 90X102+1.6(mm)
H52G 2191 1
美纹胶带
H52G1701 1
MESH PRINTTING_PAPER
