18.5"
LCD
Color
Monitor
AOC
e936Swa
49
2.) No Backlight
715G3823P01000004S
Check C802(+)=12V
NG
OK
Check adapter and MB
Check ON/OFF sign
al
Check main board
NG
OK
Check Q801 PIN5,6.7,8=12V
NG
OK
Change Q801
Check IC801 PIN1,2,3,4,5,6,7,8 have the
output of square wave at short time
NG
OK
Change IC801,IC802
Check connect
er & lamp
48
50
Table of Contents
Description Table of Contents
1
Table of Contents
1
Important Safety Notice
2
Revision List
2
Monitor Specification
3
Revision List
3
LCD Monitor Description
4
Monitor Specification
4
Adjusting the Picture
5
Control Button
5
General Instructions
5
LCD Monitor Description
5
Operation Instruction
5
Adjusting the Picture
6
Control Button
6
General Instructions
6
Operating Instructions
6
Operation Instruction
6
Input Signal Connector
8
Input/Output Specification
8
Factory Preset Display Modes
9
Display Characteristics
10
Optical Characteristics
10
Panel Specification
10
Parameter Guide Line for CCFL Inverter
10
Input Signal Connector
12
Input/Output Specification
12
Factory Preset Display Modes
13
Display Characteristics
14
Panel Specification
14
Optical Characteristics
16
Electrical Characteristics
19
Block Diagram
22
Block Diagram 6.1 Software Flow Chart
22
Electrical Block Diagram
24
Main Board
26
Schematic
26
Power Board
31
Main Board
36
PCB Layout
36
Power Board
38
Key Board
43
USB Board
43
Equipments and Tools Requirement
44
Maintainability
44
Trouble Shooting
45
Firmware and DDC Instruction
52
White-Balance, Luminance Adjustment
53
Monitor Exploded View
55
BOM List
