AOC E936SWA - Electrical Block Diagram

18.5" LCD Color Monitor AOC e936Swa
24
6.2 Electrical Block Diagram
6.2.1 Scalar Board
FLASH MEMORY
MX25L2026MI
(U402)
Scalar TSUM1PFR-LF
(Include : MCU,ADC,OSD etc)
(U401)
LCD Interface
(CN405)
D-Sub
Connector
(CN101)
Crystal 14.31818MHz
(X401)
Key Control
Interface
(CN409)
EEPROM
M24C02
(U105)
DDC1_SDA
DDC1_SCL
