AOC E936SWA Service Manual

18.5" LCD Color Monitor AOC e936Swa
62
R002 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R005 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
R006 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
R007 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
R004 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
C001 065G0603102 31 CHIP 1000PF 50V NPO
C002 065G0603225 A5 CHIP 2.2uF 10V X5R
LED001 081G15BY 2 GP LED GPTD1204BOC1-A GP
ZD004 093G 39S 34 T UDZSNP5.6B ROHM
ZD005 093G 39S 34 T UDZSNP5.6B ROHM
715G3371 2 KEY BOARD PCB
CN802 033G801910Y H FPC CONN. 0.5mm SMT 10P
CN801 033G803210F HR CONNECTOR
IC801 056G 379167 IC TA9690GN-A-0-TR SOP-24
Q801 057G 763 92 FET P8008HV 4A/80V SOP-8
R844 061G0603100 JT RST CHIP 10R 1/10W 5% TZAI YUAN
R807 061G0603100 JT RST CHIP 10R 1/10W 5% TZAI YUAN
R814 061G0603100 JT RST CHIP 10R 1/10W 5% TZAI YUAN
R812 061G0603101 JT RST CHIP 100R 1/10W 5% TZAI YUAN
R810 061G0603102 JT RST CHIP 1K 1/10W 5% TZAI YUAN
R806 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN
R813 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN
R809 061G0603104 JT RST CHIP 100K 1/10W 5% TZAI YUAN
R822 061G0603105 JT RST CHIP 1M 1/10W 5% TZAI YUAN
R826 061G0603109 JT RST CHIP 1R 1/10W 5% TZAI YUAN
R827 061G0603109 JT RST CHIP 1R 1/10W 5% TZAI YUAN
R828 061G0603109 JT RST CHIP 1R 1/10W 5% TZAI YUAN
R829 061G0603109 JT RST CHIP 1R 1/10W 5% TZAI YUAN
R831 061G0603109 JT RST CHIP 1R 1/10W 5% TZAI YUAN
R833 061G0603109 JT RST CHIP 1R 1/10W 5% TZAI YUAN
R805 061G0603124 JT RST CHIP 120K 1/10W 5% TZAI YUAN
R804 061G06033002FT RST CHIP 30K 1/10W 1%
R823 061G0603333 JT RST CHIP 33K 1/10W 5% TZAI YUAN
R824 061G06034302FT RST CHIPR 43KOHM 1% 1/10W TZAI YUAN
R825 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN
F801 061G12060004JT RST CHIP MAX 0R05 1/4W TZAI YUAN
R801 061G1206308 JT RST CHIPR 0.3 OHM +-5% 1/4W
R802 061G1206308 JT RST CHIPR 0.3 OHM +-5% 1/4W
C816 065G060310432K A CAP CHIP 0603 100nF K 50V X7R
C805 065G060347412K T CAP CHIP 0603 0.47UF K 16V X7R
C815 065G080510432K A CAP CHIP 0805 100nF K 50V X7R
C814 065G080510432K A CAP CHIP 0805 100nF K 50V X7R
C801 065G080510432K A CAP CHIP 0805 100nF K 50V X7R
C807 065G080522512K A CAP CHIP 0805 2.2uF K 16V X7R
C806 065G080522525K T CAP CHIP 0805 2.2uF K 25V X5R
L801 073G253S 80 DN SMD CHOKE 22uH 2.16A LZ.3A220.A1P HF
ZD801 093G 60S 31 T DIODE B360B 3A/60V SMB
E715 715G3823P01000004S CONVERTER BOARD PCB
C503 065G0603104 12 CER2 0603 X7R 16V 100N P
C501 065G0603509 31 CHIP 5PF +-0.5PF 50V NPO
C502 065G0603509 31 CHIP 5PF +-0.5PF 50V NPO
