18.5" LCD Color Monitor AOC e940Swa
19
6.2 Electrical Block Diagram
6.2.1 Scalar Board
FLASH MEMORY
Pm25LD020C-SCE
(U402)
Scalar NT68668AFG
(Include :MCU,ADC,OSD etc)
(U401)
LCD Interface
(CN301)
D-Sub
Connector
(CN101)
H sync
V sync
RGB
EEPROM
AT24C02BN
(U101)
DDC1_SCL
DDC1_SDA
Crystal 12MHZ
(X401)
Key Control
Interface
(CN401)
