AOC e940Swa User Manual
4
of 1
of 1 rating
56 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
18.5"
LCD
Color
Monitor
AOC
e940Swa
42
2. No Backlight
Check C802(+)=12V
Check adapter and MB
Check ON/OFF sign
al
Check main board
Check Q801 PIN5,6,7,8=12V
Change Q801
Check IC801,IC802 Pin1,
2,
3,4,5,6,7,8,9 have
the output of square wave at short time
Check IC801,IC802
Check connecter & lamp, feedback an
d protect circuit
