AOC E943FWS User Manual

41
11. BOM List
Note: The parts information listed below are for reference only, and are subject to change without notice. Please go
to http://cs.tpv.com.cn/hello1.asp
for the latest information.
T8AJNY2BZ3K2NNF.LF
Location Part No. Description Remark
040G-58162435A P/N LABEL FOR MANUAL PE BAG
040G-581689-4A BARCODE LABEL FOR 1
052G---1150--C INSULATING TAPE
085G-583576 GASKET_ELECTRIC
089G-725HAA-DB D-SUB CABLE
E08901 089G404A15N-IS AC POWER CORD 1500MM EUROPE REG.
089G404A15N-CX AC POWER CORD 1500MM EUROPE REG. 2
nd
source
E09503 095G176J-10572 FFC CABLE 10PIN 543MM 0.5MM
095G176W-10572 FFC CABLE 10PIN 543MM 0.5MM 2
nd
source
S95G176T10572 LVDS ASS'Y
E09502 095G8014-7D605 HARNESS 7P-7P(A1253HA HR) 120MM
095G8014-7L605
WIRE HARNESS 7P-7P(A1253HA HR)
120MM
2
nd
source
E09501 095G8018-3DJ52 HARNESS 30P-30P 420MM
095G8018-3XJ52 HARNESS 30P-30P 420MM 2
nd
source
0M1G-140--6125 SCREW
0M1G-140--8125 SCREW
0M1G-940--5125 .CREW
0M1G1030--6120 SCREW M3X6
0Q1G-140-10120 SCREW
708G805701S-1A AOC 40 PAPER SLIPSHEET(1932) ASS'Y
708G8057-CP AOC 40(1840) ASS'Y
Q50G---4-10 TIE (Y1900221)
Q52G---1185-99 BIG CARTON TAPE FOR AOC
750GMT185W2A21N000 PANEL LM185WH2-TRA2 FQ LTD
2436L-1641A LM185WH2-TRA2-6F1-A0
3110T-0704A
GALVALUME, T=0.3,
LM185WH2-TRA1-6F1-A0
3850L-0088A ID, YUPO, 78X37
4296L-0284A
PMP-P2 100-520U-13, 5U-C60 BLACK A600,
180X7X0.45
6060L-1838A LM185WH2-TRA2-6F1-A0
6061L-1513A LM185WH2-TRA1-611
6871L-2339A
SOURCE, SINGLE,
LM185WH2-TRA2-6F1-A0
C66 0CH2103K562 10NF, K, 50V, X7R, 0.9MM, 1608, R/TP
