AOC E943Swn Service Manual

44
UC1 0ITLL-0042A
TL2335ML, TLI, LVDS, 6/8, 1, MINI-LVDS, 6,
1-3PAIR, DRD, GIP, AFRC, DGA, QUARK,
MLF, TR, 56
L1 0LCAA-0069B
TNI8016-100M, DACOWELL, 10UH, M=20%,
2.1A, 0.093, 8.0X11.0X1.8 (1.2MM,
IN-BOARD), R/TP
FL1,FL2,FL3,R106,R107,
R133,R14,R142,R17,R17
7,R180,R181,R182,R183,
R19,R201,R211,R214,R2
15,R216,R217,R4,R72,R7
7,R81,R88,R97
0RH0000C622 0 OHM 1/16W 1608 5% D R/TP
R131,R132 0RH0221C622 2.2 OHM 1/16W 1608 5% D R/TP
R1,R2 0RH1000C422 100 OHM 1/16W 1608 1% D R/TP
R3 0RH1001C422 1K OHM 1/16W 1608 1% D R/TP
R15,R213,R22,R74,R79 0RH1002C422 10K OHM 1/16W 1608 1% D R/TP
R94 0RH1301C422 1.3K OHM 1/16W 1608 1% D R/TP
R108,R90 0RH1502C422 15K OHM 1/16W 1608 1% D R/TP
R83 0RH1601C422 1.6K OHM 1/16W 1608 1% D R/TP
R42,R78 0RH1602C422 16K OHM 1/16W 1608 1% D R/TP
R95 0RH1801C422 1.8K OHM 1/16W 1608 1% D R/TP
R137 0RH2000C422 200 OHM 1/16W 1608 1% D R/TP
R13 0RH2202C422 22K OHM 1/16W 1608 1% D R/TP
R20,R21,R61 0RH2401C422 2.4K OHM 1/16W 1608 1% D R/TP
R103,R212 0RH2402C422 24K OHM 1/16W 1608 1% D R/TP
R41,R44 0RH2700C422 270 OHM 1/16W 1608 1% D R/TP
R89 0RH2702C422 27K OHM 1/16W 1608 1% D R/TP
R57,R60 0RH3001C422 3K OHM 1/16W 1608 1% D R/TP
R105 0RH3002C422 30K OHM 1/16W 1608 1% D R/TP
R49,R52,R62 0RH3301C422 3.3K OHM 1/16W 1608 1% D R/TP
R58 0RH3601C422
3.6K OHM, 1/16W(1608), 1 PER, D-TYPE,
R/TP
R104 0RH3602C422 36K 1/16W 1% 1608
R84 0RH3901C422 3.9K OHM 1/16W 1608 1% D R/TP
R64,R65,R68 0RH4301C422 4.3K OHM 1/16W 1608 1% D R/PT
R85 0RH4703C422 470KOHM 1 / 16 W 1608 1% D R/TP
R69,R70,R71,R73 0RH5100C422 510 OHM 1/16W 1608 1% D R/TP
R82 0RH5102C422 51K OHM 1/16W 1608 1% D R/TP
R53,R56 0RH5601C422 5.6K OHM 1/16W 1608 1% D R/TP
R66,R87 0RH6200C422 620 OHM 1/16W 1608 1% D R/TP
R99 0RH6801C422 6.8K OHM 1/16W 1608 1% D R/TP
