AOC E960SWDA Service Manual

55
E750
750GMT185W2C21M1
00
PANEL LM185WH2-TRC2
2436L-2229B LM185WH2-TRC2-TF2-A0
3110T-0704A GALVALUME, T=0.3, LM185WH2-TRA1
3850L-0088A ID, YUPO, 78X37
4296L-0284A
PMP-P2 100-520U-13, 5U-C60 black A600,
180x7x0.45
6060L-1838B LM185WH2-TRC2-TF1-A0
6061L-1513B
LM185WH2(TRC1,T1C1/T1C2/T1C3/T1C4,TRC2
)
0ILUL-0168A
LS0608D3-CBLS, LUSEM, 690, 6BIT, MINI, C_B,
R/TP, 35MM, 4PF, UPILEX, T8-HD
6308L-1854A
LTBXNSSNEX5-01850T21,422.6 X
238.1,LGC,T,B,X,N,S,S,N,E,X,5,01850,TOP,21
6308L-2250A
OTBXNSSNEXG-0185022T, 422.60*238.10,
OPTIMAX, T, B, X, N, S, S, N, E, X, G, 0185, Top,
22
2nd
SOURCE
6308L-1855A
LTXXNSSNEX5-01850B21, 422.6 X 238.1, LGC,
T, X, X, N, S, S, N, E, X, 5, 01850, BOTTOM, 21
6308L-2251A
OTXXNSSNEXG-0185022B, 422.60*238.10,
OPTIMAX, T, X, X, N, S, S, N, E, X, G, 0185,
Bottom, 22
2nd
SOURCE
6871L-2339B Source, Single, LM185WH2-TRC2-TF1-A0
C66 0CH2103K562 10NF, K, 50V, X7R, 0.9mm, 1608, R/TP
C61,C8,C86,C9 0CH2104K562 0.1UF 50V K X7R 1608 R/TP
C63,C64,C65 0CH2473H562 47nF, K, 25V, X7R, 0.9mm, 1608, R/TP
C10,C3,C5,C6,C7,C90 0CH2A-0007A
1U F, 10 Volt, K PER, X5R(JB), 1608 R/TP,
T=0.9(MAX)
C70,C71 0CH2A-0010A 33nF, M, 25V, X7R, 0.9mm, 1608, R/TP
C73 0CH2A-0011A
10U F, 16 Volt, K PER, X5R(JB), 3216 R/TP,
T=0.95(MAX)
C1,C135,C137,C139,C
41,C42,C43,C44,C45,
C46,C47,C48,C49,C50
,C51,C52,C53,C54,C8
4,C92,C98
0CH2A-0015A 1uF, K, 25V, X5R, 0.9mm, 1608, R/TP
C87 0CH2A-0017A
2.2U F, 10 Volt, K PER, X5R(JB), 1608 R/TP,
T=0.9(MAX)
C151,C152,C153,C68,
C69,C80,C81,C83
0CH2A-0026A
10U F, 25 Volt, K PER, X5R(JB), 3225 R/TP,
T=1.0(MAX)
C62 0CH2A-0034A 10U F, 25 Volt, K PER, X5R(JB), 3216 R/TP,
