AOC E960SWDA Service Manual

56
T1.0(MAX)
C89 0CH5471K412 470PF, J, 50V, 1608, R/TP, 0.9mm
D1,D2,D3 0DHZL-0008B BAV99-7-05-F, DIODES, SOT-23, R/TP
ZD1 0DHZL-0061A SDZ6V2D, AUK, SOD-323, R/TP
D4 0DHZL-0095A RB050M-30, ROHM, PMDU, R/TP
F1 0FFST-0003A
Fast Blow Fuse ** F0603FA2000V032TM, AEM,
Ceramic, 32V, 2A, UL/CSA, 1.6X0.8X0.8, R/TP
U2 0ISGL-0008C
M24C04-RDW, STmicroeletronics, 4K, 5ms,
TSSOP, R/TP, 8
0ISKL-0001A
S-24CL04A0I-T8T1GE, SEIKO INSTRUMENTS,
4k, 4ms (typ), TSSOP, R/TP, 8
2nd
SOURCE
US1 0ISML-0006A
SM4023, SILICONMITUS, NOTEBOOK, 8CH
L/S+BOOST+OP-AMP+D/C+LDO+PVCOM+GPM
, 6*6 QFN, R/TP, 48
UC1 0ITLL-0042A
TL2335ML, TLI, LVDS, 6/8, 1, MINI-LVDS, 6,
1-3PAIR, DRD, GIP, AFRC, DGA, QUARK, MLF,
TR, 56
L1 0LCAA-0069A
TNI8016-100M, DACOWELL, 10UH, M20, 2.1A,
0.093, 8.0X11.0X1.8 (1.2MM,IN-BOARD), R/TP
FL1,FL2,FL3,R106,R1
07,R133,R14,R142,R1
7,R177,R180,R181,R1
82,R183,R19,R201,R2
11,R214,R215,R216,R
217,R4,R72,R77,R81,
R88,R97
0RH0000C622 0 OHM 1/16W 1608 5% D R/TP
R131,R132 0RH0221C622 2.2 OHM 1/16W 1608 5% D R/TP
R1,R2 0RH1000C422 100 OHM 1/16W 1608 1% D R/TP
R3 0RH1001C422 1K OHM 1/16W 1608 1% D R/TP
R15,R213,R22,R74,R7
9
0RH1002C422 10K OHM 1/16W 1608 1% D R/TP
R94 0RH1301C422 1.3K OHM 1/16W 1608 1% D R/TP
R108,R90 0RH1502C422 15K OHM 1/16W 1608 1% D R/TP
R83 0RH1601C422 1.6K OHM 1/16W 1608 1% D R/TP
R42,R78 0RH1602C422 16K OHM 1/16W 1608 1% D R/TP
R95 0RH1801C422 1.8K OHM 1/16W 1608 1% D R/TP
R137 0RH2000C422 200 OHM 1/16W 1608 1% D R/TP
R13 0RH2202C422 22K OHM 1/16W 1608 1% D R/TP
R20,R21,R61 0RH2401C422 2.4K OHM 1/16W 1608 1% D R/TP
R103,R212 0RH2402C422 24K OHM 1/16W 1608 1% D R/TP
R41,R44 0RH2700C422 270 OHM 1/16W 1608 1% D R/TP
