AOC E960SWDA Service Manual

57
R89 0RH2702C422 27K OHM 1/16W 1608 1% D R/TP
R57,R60 0RH3001C422 3K OHM 1/16W 1608 1% D R/TP
R105 0RH3002C422 30K OHM 1/16W 1608 1% D R/TP
R49,R52,R62 0RH3301C422 3.3K OHM 1/16W 1608 1% D R/TP
R58 0RH3601C422 3.6K ohm, 1/16W(1608), 1 PER, D-Type, R/TP
R104 0RH3602C422 36K 1/16W 1% 1608
R84 0RH3901C422 3.9K OHM 1/16W 1608 1% D R/TP
R64,R65,R68 0RH4301C422 4.3K OHM 1/16W 1608 1% D R/PT
R85 0RH4703C422 470KOHM 1 / 16 W 1608 1% D R/TP
R69,R70,R71,R73 0RH5100C422 510 OHM 1/16W 1608 1% D R/TP
R82 0RH5102C422 51K OHM 1/16W 1608 1% D R/TP
R53,R56 0RH5601C422 5.6K OHM 1/16W 1608 1% D R/TP
R66,R87 0RH6200C422 620 OHM 1/16W 1608 1% D R/TP
R99 0RH6801C422 6.8K OHM 1/16W 1608 1% D R/TP
R46 0RH8201C422 8.2K OHM 1/16W 1608 1% D R/TP
R45,R48 0RH9100C422 910 OHM 1/16W 1608 1% D R/TP
R50,R54 0RH9101C422 9.1K OHM 1/16W 1608 1% D R/TP
AR11,AR12 0RHZL10005A 100OHM 5 1/16W 3216 R/TP
CN1 311GL100F30DST--01 LVDS CONN 30P 1.0mm STM
311GL100F30DPT--01 LVDS CONN 30P 1.0mm P-TWO
2nd
SOURCE
6630L-0157B
FI-XB30SL-HF10, JAE, 30 Pin, 1 mm, Angle, Sn,
USER LOCK
2nd
SOURCE
FL4 6200L-J015A BLM18PG300SN1D
6870S-1108B
LM185WH2-TRA2-6F1-A0, 2L, 0.6t, 339.0 X 38.0,
4, R, 72, Source
6091L-1299C LM185WH2-TRA2-6F2-A0
6091L-1299D LM185WH2-TRA2-6F2-A0
2nd
SOURCE
3022L-1150A KOLON, XC210, T=0.123, LM185WH2-TRA1
3032L-0845A
LGE, MOS-T2-227, T=0.230, Angle = 4?,
LM185WH2-TRA1
3550B-0694A AL, T=0.5, LM185WH2-TRA1
3850L-0151A BL, YUPO, 77X21
4000L-0036B
SWCH18A, TAP-TITE B, PAN HEAD, M2.0, L2.5,
ELECTROLESS NI
4975L-0332A LM185WH2-TRA1-6F1-A0
4296L-0241A
SJ CHEMICAL, SJC #101, SILICONE, Gray,
TERAOKA 767, 417.2*1.2*0.25
4296L-0244A
SJ CHEMICAL, SJC #101, SILICONE, Gray,
TERAOKA 767, 236.5*1.3*0.25
