AOC E960SWDA - 5 Block Diagram

29
5. Block Diagraam
5.1 Main Board
POWER BOARD
DIM
ON/OFF
Feedback Circuit
D801
L801
PWM Control
MP3389EF
(U801)
14.5V
LED
(CN803)
MOSFET
(Q806)
Power Board
CRYSTAL
14.3181MHZ (X401)
Flash Memory
Pm25LD020C-SCE
(U402)
Scalar IC TSUMU58VHN
(Include ADC, OSD, MCU)
(U401)
Panel Interface
(CN701)
Key Control Interface
(CN404)
D-Sub Connector
(CN101)
DVI Connector
(CN102)
