AOC e960Swn User Manual

32
6.2 Key Board
715G5357K01000001S
LBADC2
DC_POWERON
SUB UY
LED001
LED
1
2
3
9 5 G 8 2 0 H - 6 W / D - 5 2 0 2 6 0 M M
BLUE
R001 100R 1/10W 5%
POWERPOWER 0.083V
OEM MODEL Size
Rev
Date
Sheet
of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹 e2460Swg B
AOC
B
12Wednesday , February 15, 2012
715G5357-K0B-000-0010
<
称爹 >
2.0.key
G5357-K0B-000-0010
( 100 ohm )
ZD001NC/MLVS0603M04
1 2
DOWN
LBADC2
UP
(AUTO)(DOWN-)
(2K)
(UP+)
POWER
ZD002NC/MLVS0603M04
1 2
MENU
( 100 ohm )
CONNECTOR
(MENU)(Power)
AUTO(2.0K)
LBADC1
0.083V
1.118V
ZD003NC/MLVS0603M04
1 2
MENU
UP
ZD004NC/MLVS0603M04
1 2
DOWN
ZD005NC/MLVS0603M04
1 2
AUTO
ZD006MLVS0603M04
1 2
ZD007MLVS0603M04
1 2
SGND
LED
SGND
SW002SW SW003SW SW001SW SW004SW
R004 2KOHM 1/10W
R003 100R 1/10W 5%
R005 2KOHM 1/10W
SW005SW
R002 1K 1/10W 5%
LBADC1
LED_2#
1.118V
0.673V
(1K)
CN001
Wire Harness
1
2
3
4
5
6
SGND
SGND
LED_1#

AOC e960Swn Specifications

General

Aspect ratio	-
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewing angle, vertical	50 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	600:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	90 °
Digital vertical frequency	50 - 76 Hz
Digital horizontal frequency	30 - 60 kHz
Display brightness (typical)	200 cd/m²
Display viewable area (HxV)	409.8 x 230.4 mm
Tilt angle range	5 - 20 °
Panel mounting interface	100 x 100 mm
AC input voltage	90 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	18 W
Certification	TCO 5.2, CE/CB, cTUVus, FCC, CCC, EPA 5.2, CH RoHS, CEL 1
Product color	Black
Compliance industry standards	DDC2B, DDC2B/CI
Sustainability certificates	EPEAT Gold, ENERGY STAR
Package depth	114 mm
Package width	493 mm
Package height	422 mm
Package weight	3200 g

Weight and Dimensions

Depth (without stand)	185 mm
Width (without stand)	440 mm
Height (without stand)	346 mm
Weight (without stand)	2080 g
