AOC E970SWN

37
Panel
Product name
E2270SWN
Driving system
TFT Color LCD
Viewable Image Size
54.7cm diagonal
Pixel pitch
0.2482mm(H)X0.2482mm(V)
Video
R, G, B Analog lnterface
Separate Sync
H/V TTL
Display Color
16.7M Colors
Dot Clock
148.5 MHz
Resolution
Horizontal scan range
30 kHz - 83 kHz
Horizontal scan Size(Maximum)
476.64mm
Vertical scan range
50 Hz - 76 Hz
Vertical scan Size(Maximum)
268.11mm
Optimal preset resolution
1920x 1080 (60 Hz)
Plug & Play
VESA DDC2B/CI
Input Connector
D-Sub 15pin
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM
Power Source
100-240V~, 50/60Hz
Power Consumption
Active： 18 W(typical)
Standby < 0.5 W
Physical
Characteristics
Connector Type
15-pin Mini D-Sub
Signal Cable Type
Detachable
Environmental
Temperature
Operating
0° to 40°
Non-Operating
-25°to 55°
Humidity
Operating
10% to 85% (non-condensing)
Non-Operating
5% to 93% (non-condensing)
Altitude
Operating
0~ 3658m (0~ 12000 ft )
Non-Operating
0~ 12192m (0~ 40000 ft )
