AOC E970SWN

36
Specification
General Specification
Panel
Product name
E970SWN/E970SWNL
Driving system
TFT Color LCD
Viewable Image Size
47.00cm diagonal
Pixel pitch
0.3 mm(H) x 0.3 mm(V)
Video
R, G, B Analog lnterface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Dot Clock
85.5MHz
Resolution
Horizontal scan range
30 kHz - 60 kHz
Horizontal scan Size(Maximum)
409.8mm
Vertical scan range
50 Hz - 76 Hz
Vertical scan Size(Maximum)
230.4mm
Optimal preset resolution
1366x768(60 Hz)
Plug & Play
VESA DDC2B/CI
Input Connector
D-Sub 15pin
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM
Power Source
100-240V~, 50/60Hz
Power Consumption
Active：15 W(typical)
Standby < 0.5W
Physical
Characteristics
Connector Type
15-pin Mini D-Sub
Signal Cable Type
Detachable
Environmental
Temperature:
Operating
0° to 40°
Non-Operating
-25°to 55°
Humidity:
Operating
10% to 85% (non-condensing)
Non-Operating
5% to 93% (non-condensing)
Altitude:
Operating
0~ 3658m (0~ 12000 ft )
Non-Operating
0~ 12192m (0~ 40000 ft )
