AOC G2460PG - Specification; General Specification

46
Specification
General Specification
Panel
Model name G2460PG
Driving system TFT Color LCD
Viewable Image Size 61.0 cm diagonal
Pixel pitch 0. 27675 mm(H) x 0. 27675 mm(V)
Video DP Interface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Dot Clock 325.08MHz
Resolution
Horizontal scan range 30kHz~160kHz
Horizontal scan Size(Maximum) 531.36 mm
Vertical scan range 30Hz~150Hz
Vertical scan Size(Maximum) 298.89 mm
Optimal preset resolution 1920 x 1080 (144Hz)
Plug & Play
VESA DDC2B™
Input Connector DP
Input Video Signal DP
Output Connector NA
Power Source 19Vdc，3.42A
Power Consumption
Active 33 W (typical)
Standby < 0.5 W
（
after 15 minutes of no signal monitor will
go into standby mode）
Off timer 0~24 hrs
Speakers NA
Physical
Characteristics
Connector Type DP
Signal Cable Type Detachable
Environmental
Temperature
Operating 0° to 40°
Non-Operating -25°to 55°
Humidity
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 93% (non-condensing)
