AOC G2460VQ6 User Manual

6
Installation
Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a
person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by
the manufacturer or sold with this product. Follow the manufacturer’s instructions when installing the product and
use mounting accessories recommended by the manufacturer. A product and cart combination should be moved
with care.
Never push any object into the slot on the monitor cabinet. It could damage circuit parts causing a fire or
electric shock. Never spill liquids on the monitor.
Do not place the front of the product on the floor.
If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit
instructions.
Leave some space around the monitor as shown below. Otherwise, air-circulation may be inadequate hence
overheating may cause a fire or damage to the monitor.
See below the recommended ventilation areas around the monitor when the monitor is installed on the wall or on
the stand:

AOC G2460VQ6 Specifications

General

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
External power adapter	No
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	23 W
Panel type	TN
Pixel pitch	0.276 x 0.276 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	Matt
Pixel frequency	165 MHz
Display diagonal	24 \
Display technology	LCD
Vertical scan range	48 - 76 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	1080p
Viewable size, vertical	298.89 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	531.36 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Tilt angle range	-5 - 20 °
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
Built-in camera	-
RMS rated power	4 W
Number of speakers	2
Certification	ISO
Product color	Black
Front bezel color	Black/Red
Heavy metals free	Hg (mercury)
Market positioning	Gaming
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Package type	Box
Package depth	131 mm
Package width	621 mm
Package height	476 mm
Package weight	6100 g
VGA cable length	1.8 m
Cables included	AC, Audio (3.5mm), DisplayPort, HDMI, VGA
Sustainability certificates	RoHS, ENERGY STAR
AMD FreeSync type	FreeSync
AMD FreeSync refresh rate range	30 - 144 Hz
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	219.3 mm
Height (with stand)	411.6 mm
Weight (with stand)	4270 g
Depth (without stand)	78.2 mm
Width (without stand)	565.4 mm
Weight (without stand)	- g
