AOC I2369Vm

26
4.3.3 Electrical Characteristics
Parameter Symbol
Values
Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VLCD 4.5 5.0 5.5 Vdc
Permissive Power Input Ripple VLCD - - 0.3 V 1
Power Supply Input Current ILCD
60Hz - 790 1030 mA
2
(Not fixed)
75Hz - - 1250 mA
60Hz - 960 1250 mA
3
(Not fixed)
75Hz - - 1550 mA
Power Consumption
PLCD_TYP
(@60Hz)
- 3.95 5.15 Watt 2
PLCD_MAX
(@60Hz)
- 4.8 6.25 Watt 3
Inrush current IRUSH - - 3.5 A 4
LED bar Electrical characteristics
Parameter Symbol
Values
Unit Notes
Min. Typ. Max.
LED String Current Is - 85 90 mA 1, 2, 5
LED String Voltage Vs 44.8 48.0 51.2 V 1, 5
Power Consumption PBar - 12.2 13.1 Watt 1, 2, 4
LED Life Time LED_LT 30,000 - - Hrs 3
