AOC I2369Vm Service Manual

50
11. BOM List
Note: The parts information listed below are for reference only, and are subject to change without notice. Please go
to http://cs.tpv.com.cn/hello1.asp
for the latest information.
HDCJV27BFVK2DNF.LF
Location Part No. Description Remark
040G-581689-4A
BARCODE LABEL FOR 1
(58x35mm)
041G--68508--A control card
052G---1150--C
黑色防静电胶带 INSULATING TAPE
052G---1209--A 200MINIUM TAPE
052G---1211--B
Conductive Tape 85mm *40mm
*0.09mm (单导)
052G---2191--A PAPER TAPE
052G6019--1 INSULATING TAPE
055G--23522
氢氟醚 HFE3400
E08904 089G-17356G554 AUDIO CABLE 1800MM GREATLAND
089G-17356C554 AUDIO CABLE 1800MM COMLINK 2nd source
E08902 089G-725CAA-DB SINGAL CABLE 1500MM COMLINK
089G-725HAA-DB SINGAL CABLE 1500MM HONGLIN 2nd source
089G-725GAA-DB SINGAL CABLE 1500MM GREATLAND 2nd source
089G-725LAA-DB SINGAL CABLE 1500MM HONGSHUO 2nd source
E08901 089G404A15N-CX
POWER CORD 1500MM Europe
XUEXIANG
089G404A15N-YH
POWER CORD 1500MM EUROPE
YUNHUAN
2nd source
089G404A15N-IS
POWER CORD 1500MM Europe
I-SHENG
2nd source
089G404A15N-HL
POWER CORD 1500MM Europe
HONGLIN
2nd source
089G404A15N-JR POWER CORD 1500MM Europe jianrun 2nd source
0D1G1030--6120 screw
0M1G1140--6120 screw
0M1G3030--4120 SCREW FOR PANEL
0M1G3030--5-47-CR3 SCREW
0Q1G-930--8120 SCREW 3X8
708GDF4501S-1A AOC 40EU(1302)
F44G1200-SL100 Slipsheet 1200×1000
F44G560K260380 Empty Carton
F44G600K-70260 Empty Carton
Q44G6002118-97 PAPER BOARD
Q44G9003214 CONNER PAPER

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
