AOC I2369Vm Service Manual

51
Q45G--77--5 PE PACKING (Y1900241)
Q50G---4-10 TIE (Y1900221)
Q52G---1185-98 3M TAPE
7250L-0484A Conductive tape, Black, 14*25*0.1mm
7250L-0484B Conductive tape, Black, 20*35*0.1mm
750SMT230W3F21N100 PANEL LM230WF3-S2F2
2436L-3229A LM230WF3-S2F2-K31
3110T-1040A EGI , 0.5T,LM230WFA-S2Z2
3550S-1466D AL7um,PET75um,438.3*37.2*0.1
3850L-0088A ID, YUPO, 78X37
6091L-2369A LM230WF3-S2F2
3022L-1928A
TORAY, TDF127, T0.145,
LM230WF3-S2D2
3022L-2236A LU963 , Kolon
3034L-1201A T6D6, Toray
3551L-0791A LM230WF3-S2F2, 'B' type
3550B-1104B GALVALUM , 0.8T, 'B' type
4296L-0284C KE951+Nitto 5000NS, black, 4x4x2
6916L-1247A LG INNOTEK, 8520E(YR), 48ea
5153L-0120A 05010HR-H10H , YEON-HO
6915L-0512A
LGIT LED,Top View,2ea(LED Chip Q'TY
per PKG), 8520E
PKG,BM215WF4-T2G2
6920L-0307A 520.6 x 4.5 x 1.0
7250L-2289A
PD-25TT, 519.6*3.9*0.25, Thermal
Conductivity
3850L-0151A BL, YUPO, 77X21
4975L-0630A LM230WF3-S2D2
4974L-1103A PC,ENTIRE,ETR-1010,V0 , BLACK
4974L-1104A PC,ENTIRE,ETR-1010,V0 , BLACK
7250L-2251A
3M, 4734-64B, Black, 520.2*5*0.64,
Fixing
7250L-2251B 3M, 4734-64B, Black, 297*5*0.64, Fixing
7250L-2251C
3M, 4734-64B, Black, 513.8*4*0.64,
Fixing
5151L-0316A LM230WF3-S2D2
3953L-0160J
TORAY, E60L, 3M 1363-60,
288.1*1.5*0.188, LM230WF3-SSA1
3953L-0160K
TORAY, E60L, 3M 1363-60,
489.0*1.5*0.188, LM230WF3-SSA1
5150L-0831A PMMA, Flat, T2.0,

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
